30x15m ice rink HDPE barrier dasher boards :

We provide complete solutions for synthetic ice rink systems. The complete set is including the base panel, fencing barrier, handrail, gate etc.


For the most solid and rigid barrier solution we advise these barriers made out of galvanised steel cladded with opaque or transparent PE panels and a 15 cm kickboard.

Panels come in standard length of 2m- 1m 0,5 m and 025 m.

standard height 1 m or 1,2m on request.



Top railing available in PE and wood

Player doors and service doors are available for access to the ice rink barrier.

With a fully enclosed barrier system the wind will have less of a negative effect on the quality of the ice compared with the open wooden barriers


Description

The ice rink boards are designed strategically to offer a boarding system which is both sturdy and quick and easy to install.

Each ice rink always includes a gated board to allow skaters access to the rink, four curve boards located in each corner of the rink, and the rest of the system is completed with straight boards adapted to the specific size of the skating rink.


ice rink ground area is 60x30m, 40x20m, 30x15m



Ice rink Barrier

Xinxing supply the complete ice rink railing/barriers/dasher board for you, it is including  panel, steel frame, steel triangular support, handrail, screw.

The installation of  ice rink railing/barriers/dasher board is easy and simple. we will design the detailed drawing of ice rink railing/barriers/dasher board according to your demand.


1. Composition of Ice rink barriers:

Xinxing could supply the complete dasher board as following items:

White Dasher Facing

Yellow Kickplate

Blue Caprail

Steel frame

SUS Screws




2. Application of ice rink barriers:

Inexpensive: Low operating and maintenance costs

Usable 365 days a year: The system can be used in any place and in any weather condition.

Easy skating: skating experience similar to that on natural ice

unaffected by the weather or place: year-round skating indoor and outdoor with every weather

Extensive use: use for leisure and professional activities

Long life services: The lifespan is significantly longer than that of the traditional plastic ice-rinks


3. ice rink barrier Protective nets made of polypropylene or high-strength polyester.

Strand thickness: 2,3 mm; 3,0 mm; 4,0 mm, eye size 3,0x3,0 cm or 3,5x3,5 cm.

The net is installed behind the ice rink bands, in places most exposed to falling out of the hockey puck.

Protective nets for ice rinks are designed to capture and slow down pucks heading towards the stands so that they do not harm the viewers watching the hockey match.

The nets are adapted to the size of the ice rink and installed in several ways.

The assembly method is delivered to the individual needs of users and the ice rink specifications.


4. Ice rink barrier usage


Permanent ice rinks, indoor mobile rinks, outdoor mobile rinks, sports events



Size

Frame Materials

Steel frame and aluminum frame is highly recommend

steel tube crosssection: 40x25mm, 60x40mm, 80x40mm, 100x50mm, 40x40mm,50x50mm, thickness can be 2.5mm, 3-5mm

aluminum tube crosssection: 76x44mm, 130x40mm, 40x40mm,  150x40mm, thickness can be 3mm and 4mm


Guard Board Materials

PP, PE, Acrylic, Tempered Glass

thickness can be 10mm and 12mm


Kick Plate

thickness can be 8mm, 10mm and 12mm


Handrail Material

PE or Customized

thickness can be 12mm and 15mm


ice rink barrier Protective nets made of polypropylene or high-strength polyester.
Strand thickness: 2,3 mm; 3,0 mm; 4,0 mm, eye size 3,0x3,0 cm or 3,5x3,5 cm.

Wideth, Length and Height is customized according to requirement.




Color

White, Yellow, Red, Blue etc, Customizable.

Applications

Permanent ice rinks, indoor mobile rinks, outdoor mobile rinks, sports events
