uhmw hopper liner :

UHMW-PE hopper Liner

uhmwpe hopper liner

uhmwpe hopper lining solution

Inquire Now Next Product

Description

UHMW-PE hopper Liner Advantages

1.Good lubrication and exceptional low abrasion coefficient character of UHMWPE sheet make it to be choosed to be the lining of many chute , coal bunker , truck liner , mixing silo lining and other project whose conveyor cohere easily when it been unloaded and delivered . Adopting UHMW-PE sheet as lining can help the company or operator save much time and money .

2.With a very low friction co-efficient and zero water absorption, UHMWPE lining are widely used to eliminate caking, bridging and hanging up of a variety of bulk materials in application extending through steel and cement production, mining and power generation. In new applications the use of UHMWPE liners facilitates shallower chute and hoper angles providing greater design freedom whilst in existing installations the simulation of steeper angles through a low friction co-efficient is often the solution to plant blockage problems.

Advantage

1. Wear resistance is 6-7 times of ordinary carbon steel;

2. impact strength was 4 to 5 times of the ABS;

3. Self-lubricating properties superior;

4. Strong corrosion resistance, high chemical technical;

5. non-stick phase is not easy to attach the product surface and other materials;

6. the impact energy absorption is strong;

7. health non-toxic, low temperature resistance, also have ductility in liquid nitrogen

TYPICAL PROPERTIES:

Excellent impact resistance

High mechanical strength

Resistant to many solvents

Very good electrical insulator

Excellent abrasion resistance

Very high damping properties

Continuous use temp. of -269 to 80 Deg. Cent.

Minimum water absorption (0.01%)

Extremely low co-efficient of friction

F.D.A. approved for food and drug industries

Size

3000x1500mm

3000x1000mm

300x1200mm

2000x1000mm

2000x1300mm

thickness can be 10mm and 12mm

Color

black, white, blue, green

Applications

UHMWPE is used in applications requiring high abrasion resistance and non-stick qualities.

Mining Liners for:

Conveyors, Truck beds, Dragline buckets, Shovels, Front loading buckets, Scrapers, Excavator buckets

Coal Preparation Liners for:

Chutes, Hoppers, Bunkers, Launderer parts, Conveyor skirting, Conveyor troughs, Coal and Ore

Transportation:

Dump truck lining, Ship Hold Liners, Rail car liners, Conveyor liners,

Bulk Material Handling:

Grain, Coal, Sand, Gravel, Urea Phosphates, Wood Chips, Kaolin Powder, Soap Powder, Dry Fertilizer, Foundry Sand, Soda Ash, Gypsum Barite, Dry Cement, Chemical Powder, Fly Ash & Bottom Ash

Data Sheet

Physical Properties	Test Method	Unit	Value
Specific Gravity	ASTM D792	g/cm3	0.93
Water Absorption	ASTM D570	℃	<0.01
Mechanical Properties	Test Method	Unit	Value
Tensile Strength	ASTM D638	MPa	40
Elongation, at break	ASTM D638	%	300
Flexural Strength	ASTM D790	MPa	24
Compression Strength, 10% Deformation	ASTM D695	MPa	21
Hardness, Shore D	ASTM D2240	-	D66
Coefficient of Friction	-	-	0.12
Thermal Properties	Test Method	Unit	Value
Heat Deflection Temperature	ASTM D648	℃	47
Melting Point	ASTM D3412	℃	135
Continuous Service Temperature	-	℃	82
Electrical Properties	Test Method	Unit	Value
Surface Resistivity	ASTM D257	Ω-M	>1015
Dielectric Constant 106Hz	ASTM D150		2.3
