uhmwpe outrigger pad and uhmwpe stabilizer pad :

UHMWPE jacking block


uhmwpe jack block


UHMWPE outrigger pad


UHMWPE stabilizer pad


UHMW-PE rigger pad


uhmwpe outrigger pad and uhmwpe stabilizer pad

uhmwpe outrigger pad and uhmwpe stabilizer pad

uhmwpe outrigger pad and uhmwpe stabilizer pad

uhmwpe outrigger pad and uhmwpe stabilizer pad


Description

Anti-slip heavy duty interlocking UHMWPE crane stacker cribbing blocks


UHMWPE heavy duty interlocking Crane stacker cribbing blocks designed to stabilise heavy equipment and machinery with the flexibility to use in various configurations.


The UHMWPE heavy duty interlocking crane stacker cribbing blocks provide you with safer, smarter cribbing solutions


Engineered to withstand high capacity loads, our heavy duty cribbing blocks are designed to support and stabilise heavy machinery and equipment during a lifting/lowering operation. Long lasting performance with minimal maintenance, our super cribbing blocks provide a much safer solution to traditional wooden cribs.


Super UHMWPE interlocking crane stacker cribbig blocks can be easily and safely setup in minutes. Each individual lightweight cribbing block has integrated rope handles which makes handling, stacking and storing simple.


Ideal for a range of applications from emergency cribbing in the event of an accident to providing axle support whilst carrying out routine maintenance on wheel bubs and braking systems.


FLEXIBLE CONFIGURATIONS

The interlocking modular design of cribbing blocks gives you the flexibility to build a crib for every type of load stabilisation and equipment levelling, whilst still being easy to move and transport.  We recommend two configurations depending on the load capacities you need to support - a 2-block layer crib and a 3-block layer crib.


Big strength and supports

Safety is critical when lifting and lowering heavy equipment. Traditionally wooden cribs have been used to provide temporary structures to support and stabilise loads, but when left outside and exposed to the elements they splinter and rot. Engineered from High Density Polyethylene (HDPE) our cribbing block products are resistant to water and chemicals.


Crane outrigger pads,Crane stabilizer jack pads    outrigger pads,stabilizer jack pads,jack pads,crane cribbing plate

UHMWPE Crane cribbing plate,UHMWPE Crane pads    HDPE crane block,HDPE Crane cribbing plate,UHMWPE Crane outrigger pads


Recycled Multi-color UHMWPE Crane outrigger pads/jack pad/foot support pad/cribbing pad  Benefits:
l Do not absorb moisture and will not swell up over time due to exposure outdoors.
l Good impact intensity, Do not lose their impact strength over time.
l Good breaking elongation,so they will bend but not break under extreme loads.
l Non-stick surface, easy to clean. l Corrosion and chemical resistant.
l Can work in in adverse weather conditions.
l Durable & Long Lasting, Cost Efficient compared to Steel or Aluminum l amazingly light compared to steel pads, and easier to mount, replace
l Will not rot,crack,splinter, or absorb moisture, safer to use in the field compared to other wood based pads.
l Lower maintenance costs.
l Storage-Friendly.

UHMWPE outrigger pads than normal outrigger pad compressive ability is stronger,more wear-resisting,and the price is low,service life is longer,not only save the cost,but also improve the efficiency so they are the best choice to replace the wood outrigger pads and become more and more popular.

size (mm) 300*300*25 300*300*30 300*300*35 300*300*40 300*300*45 300*300*50

size (mm) 400*400*25 400*400*30 400*400*35 400*400*40 400*400*45 400*400*50

size (mm) 500*500*25 500*500*30 500*500*35 500*500*40 500*500*45 500*500*50

Bigger size like 1000X1000X(40-100)MM ,2000X2000X(40-100)MM is also available with us.




Size

Thinckness
Size
Load Capacity(TONS)
Weight
MM
MM
45°
Vertical
KGS





25MM
500*500
30
55
6.25
600*600
35
60
9
800*800
40
81
16
1000*1000
43
93
25
1200*1200
50
130
36
Dia.800
38
78
12.5
Dia.1000
41
91
20
Dia.1200
48
110
28





40mm
500*500
31
56
10
600*600
36
61
14.4
800*800
42
82
25.6
1000*1000
44
94
40
1200*1200
51
131
57.6
Dia.800
40
80
20
Dia.1000
42
92
32
Dia.1200
48
130
45





50mm
500*500
31
58
12.5
600*600
40
62
18
800*800
43
85
32
1000*1000
45
98
50
1200*1200
55
140
72
Dia.800
41
83
25
Dia.1000
43
95
40
Dia.1200
52
137
56



60mm
800*800
43
86
38.4
1000*1000
45
99
60
1000*1000
53
133
86.4
Dia.800
41
84
30
Dia.1000
42
96
48


Color

black and yellow


green, red, white, orange, grey, blue


Applications

uhmw cribbing block


truck crane

crawler crane

rough crane

boom crane

concrete pump

fire truck

utility truck

tree trimmer

aerial equipment
