provides enhanced stability for outdoor applications. Xinxing UV Resistant retains all the key properties of PE 1000 and prevents premature degradation of the material under continuous UV exposure. It is ideal for agricultural, recreation and transportation applications. Parts made from Xinxing UV Resistant are self-lubricating and will not corrode or freeze, providing extended part life and improved performance.
Description
Xinxing UV Resistant has been modified for enhanced stability in outdoor applications. Applications include snowplow blades, dock-fender facings, farm machinery, snowmobile ski skins and belly-pan liners, and amusement park slides and wear components.
Xinxing UV Resistant consists of a modified formula retains all the key properties of Xinxing — low friction surface, wear and corrosion resistance, impact strength — and, exhibits enhanced stability for outdoor, UV-exposed applications.
In agricultural applications, Xinxing UV Resistant extends the life and performance of field equipment. Parts made from Xinxing UV Resistant are self-lubricating and won’t corrode or freeze, offering extended life and improved performance whether used on new machinery or as retrofits on weathered equipment.
Advantages of Xinxing UV Resistant:
Low friction surface
Wear and corrosion resistance
Excellent impact strength
UV resistant
Self-lubricating
Applications:
Airboat bottoms
Amusement park wear components
Boat rub rails
Combine skid plates
Dock fender facings
Dump trailer liners
Ice rinks
Plow board liners
Rink kick plates
Salt spinners
Sand/salt boxes
Shank protectors
Skateboard heel stops
Snowmobile belly pan liners
Snowmobile ski skins
Snowplow blades
Snowplow mold boards
Spreaders
Sprockets
Trough liners
Water slide liners
Wear strips
Size
thickness can be from 6-250mm
3000x1200mm
3000x1500mm
3000x3000mm
4500x2000mm
6000x1800mm
cut to size per clients' demands
Color
Black, Blue, Green, White, Yellow
Applications
Industries: Agriculture, Marine/Seaports, Recreation, Transportation
Applications: Airboat bottoms, Amusement park wear components, Boat rubrails, Combine skid plates, Dock fender facings, Dump trailer liners, Ice rinks, Plow board liners, Rink kick plates, Salt spinners, Sand/salt boxes, Shank protectors, Skateboard heel stops, Snowmobile belly pan liners, Snowmobile ski skins, Snowplow blades, Snowplow mold boards, Spreaders, Sprockets, Trough liners, Water slide liners, Wearstrips
Data Sheet
| Property | Method | SI Unit | SI Value |
|---|---|---|---|
| Density | ASTM D-792 | g/cm3 | 0.953 |
| Yield Point | ASTM D-638 | MPa | 20 |
| Elongation at Yield | ASTM D-638 | % | 15 |
| Tensile Break | ASTM D-638 | MPa | 45 |
| Elongation at Break | ASTM D-638 | % | 290 |
| Tensile Modulus | ASTM D-638 | MPa | 913 |
| Flexural Modulus | ASTM D-790 | MPa | 723 |
| Izod Impact (Charpy Notched Impact) | ASTM D-4020 | kJ/m2 | 113 |
| Tensile Impact | DIN 53448 | kJ/m2 | 3096 |
| Sand Wheel Wear | ASTM G-65 | T-1000=100 | 113 |
| Hardness | ASTM D-2240 | Shore D | 69 |
| Static Friction | ASTM D-1894 | Unitless | 0.18 |
| Dynamic Friction | ASTM D-1894 | Unitless | 0.15 |
| Coefficient of Thermal Exp | ASTM D-696 | �C-1 | 0.00018 |
| Melt Point | ASTM D-3417 | �C | 137-143 |
| Compressive Modulus | ASTM D-695 | MPa | na |
| Compressive Deformation | ASTM D-621 | % at 454.5kg | na |
| Volume Resistivity | ASTM D-257 | Ohm-cm | >1015 |
| Surface Resistivity | ASTM D-257 | Ohm | >1015 |
| Water Absorption | ASTM D-5706 | % | nil |
